Thanks to its intuitive interface, Ariane Live allows you to quickly enter your data and visualize the resulting stick map directly on the satellite map !
Angular profile description allows you to describe the profiles with a high level of precision and flexibility and export the resulting 3D cave model
Works on both Mac OSX (Intel based using Firefox browser) and PC (Windows 7+) and is backward compatible with Ariane 2.1
the free cave mapping solution for PC
Ariane is a new generation graphical cave mapping utility. It focuses on the visual aspect quality of the of the stick maps it produces as well as its intuitive graphical based interactions with the data. It is free for non commercial use and you can quickly learn to use it by watching the Video Tutorial
Worldwide more then 130000 feet of cave have already been mapped using Ariane.
The DRSS ( Dominican Republic Speleological Society ) is using Ariane Live for its current exploration expedition in Africa.
A profile view showing the depth/penetration distance has been added.
